| Weight |
Blue:
S: 11.5 kg
M: 11.6 kg
L: 11.7 kg
XL: 11.8 kg
Green
S: 11.3 kg
M: 11.4 kg
L: 11.5 kg
XL: 11.6 kg
Weight without pedals, with inner tubes |
| Frame |
Full carbon
1150 g in size M (gross, without hardware)
31.6 mm seat post
Compatible with dropper posts (internal routing)
Thru axle
BOOST format
PressFit 92 bottom bracket
Compatible with 2 bottle cages
Sram UDH derailleur hanger |
| Drivetrain |
Sram GX Eagle rear derailleur and shifter
Truvativ STYLO 6K crankset (170 mm in S and M, and 175 mm in L and XL)
32T chainring (compatible with 30, 32, 34 and 36T)
SRAM PG1230 11-50 cassette
Sram NX chain
Sram PF 92 bottom bracket |
| Suspension |
GREEN MODEL (8731767)
RockShox REBA RL 100 mm fork
32 mm stanchions
Motion Control valve
Thru axle
BOOST format
Combolock II handlebar lockout (2 positions: open and closed)
Weight: 1633 g
BLUE MODEL (8615562)
RockShox Recon GOLD RL 100 mm fork
32 mm stanchions
Motion Control valve
Thru axle
BOOST format
Combolock II handlebar lockout (2 positions: open and closed)
Weight: 1850 g |
| Wheels |
29" Sun Ringle Duroc 30 SRC Tubeless Ready wheels
Weight: 2070 g
HD freehub
Inner rim width: 30 mm
6-bolt rotors
32 round spokes
Sealed bearings
BOOST axles: 15 mm front and 12 mm rear
Fitted with rim tape: Tubeless Ready |
| Brakes |
Sram Level T
Sram G2 180 mm front rotor and 160 mm rear
6-bolt rotors |
| Riding position |
Rockrider aluminium stem
-7° angle
60 mm in size S
70 mm in size M
80 mm in size L
90 mm in size XL
Rockrider aluminium flat handlebar
720 mm wide
6.5° angle
256 g
Grips: Rockrider 900 Lock On |
| Saddle and seat post |
Saddle Rockrider XC Ergofit
265 g
31.6 mm aluminium
Length: 350 mm (size M) and 400 mm (size L and XL)
285 g |
| Tyre |
Front: Vittoria Barzo 29 x 2.25 Graphene
120 TPI carcass
Weight: 720 g
Rear
Vittoria Mezcal 29 x 2.25 Graphene
120 TPI carcass
Reinforced sidewalls
Weight: 760 g |
| Pedals |
Rockrider 520 Grip resin flat pedals |
| Accessories |
Your mountain bike comes with a bell, lighting, wheel reflectors, and pedals |
